CRIMPING MACHINE

Super Mute Terminal Crimping Machine

casting

castugnon

peripheral

other product

CASTING

Kodera Machine for wire processor cut strip and attached option for multifunction in one machine, you can operation easy setting on LCD touch panel.

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627

C300A

AWG#16(1.25sq) ~AWG#36(0.01sq)

CASTING C300A has been esteemed basic performance, it became the most compact design and light weight that we have ever made. It has better performance than our old model CASTING 300 and moreover has good performance of processing thin line.

C370A

AWG#10(5.5sq) ~AWG#32(0.03sq)

The compact body provides an optimum speed for mass production and ensures a high level of productivity. A very high performance even in a small-scale production of many diversified sized of wires.

C371A

AWG#7(10sq) ~AWG#28(0.08sq)

Standard wire processing machines. With attaching optional equipments, wide array of processing such as Slitting or Mid-stripping processing can be performed in addition to Cut, Strip, Half-strip, Double Sheath-strip and Divide-strip.

C371AF

AWG#7(10sq) ~AWG#28(0.08sq)

Flat cable processing machine. C371AF inherits Performance from C371A. The maximum width can be processed to cable up to 18 mmFlat cable, ribbon cable dedicated machine.

C372A

Evolved Corrugated tube cutter.

With "guillotine flat cutter " system, it's realized more beautiful cut surface of tube. For more beautiful cut surface, KODERA has developed "guillotine flat cutter". The both sides guide system of the cutter section controls the tube flexure. we reduce the deflection of the tube. To the cutting blade, also preeminent economic efficiency by adopting a (large blade) knife cutter blade that is commercially available.

C373A

AWG#7(10sq) ~AWG#28(0.08sq)

Surprising wide range and high power We've achieved a wide range of machining of AWG#2(30sq)～AWG#28(0.08sq) in one machine. It can be widely used in a wide variety of industries since it corresponds to the round cable up toφ11mm maximum diameter.

C373AF

AWG#2(30sq) ~AWG#28(0.08sq)

C373AF inherits Performance from C373A. The maximum width can be processed to cable up to 40 mmFlat cable, ribbon cable dedicated machine.

C376A

60sq~0.75sq

We've achieved a wide range of machining of 50sq-0.75sq in one machine, It can be widely used in a wide variety of industries since it corresponds to the round cable up to 17mm maximum diameter.

C377A

(Discontinuous)

80sq ~AWG#16(1.25sq)

Dual 4WD powerful stripping unit is equipped. With that power, it can process the size of maximum 80sq(20mm). which is a surprise in conventional compact machines. It ’s a reliable machine that process battery cable, WL1 and WL2 without any difficulty.

C377G

The CASTING C377G has a total of eight rollers, each driven by an independent motor. In addition, all four pairs of rollers are double-sided.

The CASTING C377G has a total of eight rollers, each driven by an independent motor. In addition, all four pairs of rollers are double-sided. The C377G's four pairs of rollers are all double-sided, ensuring that the wire pass line remains constant regardless of the wire's thickness. In addition, by opening and closing the rollers in the up/down and left/right directions, damage to the wire is minimized and the wire is always cut and stripped in a stable manner. The AC power supply has a world wide input. The machine is equipped with casters for easy transportation and installation.

C378

AWG#2~200sq

Maximum of 200sq cut and strip processing has been realized. Such thick wires have been processed by hand in the field such as cubicle, elevator, power plants where they handle high voltage electrical power lines. KODERA’S delicate technique and adventurous idea have accomplished a special machine for very large wires in diameter.

C381A

AWG#7(10sq) ~AWG#28(0.08sq)

Belt Feed has made stable measurement come true. Based on C371A, we've actualized the stable length measurement by performing the wire feeding with belt feed system. It can grasp the face of the wire whose surface is unlevel, which is often seen on shield wire.

C385A

AWG#7(10sq) ~AWG#28(0.08sq)

It doesn’t damage the core wire since stripping is performed with special round blade and cutting of the wire is processed with V-blade all together. Furthermore, belt feed system has actualized the stable length measurement because it can grasp the face of the cable whose surface is unlevel, which is often seen on cabtire cables or shield wires, etc. Switching of the belt feeding by air control can be performed at the flip of a switch on the operation panel.

CASTUGNON

KODERA FULL AUTOMATIC STRIPPING AND CRIMPING MACHINE one unit use multi function, seal insert, twisting, soldering, mid strip function

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627

C551SSA

FULL AUTOMATIC DOUBLE ENDS CRIMPING UNIT

Higher performance in a simple and compact body --- Super CASTUGNON

C555SSA

FULL AUTOMATIC DOUBLE ENDS CRIMPING UNIT & SINGLE END SEAL INSERTION UNIT.

CASTUGNON C555Se is the combination model of CASTUGNON C551Se andseal supply unit. High basic performance is same as C551Se and CFM is installed, which has been developed by the comprehensive technology of KODERA.

C558SSA

FULL AUTOMATIC DOUBLE ENDS CRIMPING UNIT & DOBLE ENDS SEAL INSERTION UNIT.

The seal can be supplied easily and speedy. Seal is indispensable for automobile harness field. The on-off of seal unit can switch by operation panel.

C550SZe

FULL AUTOMATIC SINGLE END CRIMPING UNIT

C550SZE, C550SZTE ,C550SZSE,C550SZTSE,C550SZTSWiie You can select the C550SZe basic model or any of the other models in accordance with your processing requirements and future job expasion. Alternatively, you can add on any of the options at a later date.

C556SZe

FULL AUTOMATIC SINGLE END CRIMPING UNIT & SINGLE END TWISTING AND SOLDERING, SINGLE END SEAL INSERTION UNIT.

New combination model of seal supplier and C550SZTSe which is standard machine of CASTUGNON “initial 5” series. KODERA has simply designed revolutionary compact body and basic performance of seal supplier.

C511e

(Please Call)

FULL AUTOMATIC DOUBLE ENDS CRIMPING UNIT.

CASTUGNON C511e is main machine of C51Xe series. It has inherited the performance of CASTUGNON C511e which is best-seller both ends crimper of KODERA. And C511e includes Digital Crimper and Crimp Force Monitor as standard equipment. Furthermore, C511e 3t is installed 3 metric ton press. Reasonable and high performance CASTUGNON

C515e

(Please Call)

FULL AUTOMATIC DOUBLE ENDS CRIMPING UNIT & SINGLE END SEAL INSERTION UNIT.

C551HXG

FULL AUTOMATIC DOUBLE ENDS CRIMPING UNIT. Cross roller unit standard equipment

HX series in pursuit of high-speed machining Simple & Compact, Unprecedented Capability and Surprising Processing Power Next generation full automatic crimper "CASTUGNON C551HX" made a breakthrough in the technology of wire processor. With unique concept and imagination, C551HX offers many user-friendly functions with its improved capability, easy operationality and simple applicator exchange (setup change). A good news for business owners as well;through ultimate downsizing and miniaturization of applicators,C551HX occupies as little space as possible.

C550HX

FULL AUTOMATIC SINGLE END CRIMPING UNIT SINGLE END TWISTING and SOLDERING UNIT.

The process of Strip,Crimp,Twist and Solder takes at 9000pieces/hour. Based on 551HX whose strong point is super fast processing, in order to perform the process of twisting and soldering more speedily, the twisting blade is put in the cutter block and also the compactification of the operation of changing a wire is made extreme.Flux treatment adopted the Pouring Method which is our new idea has realized the processing time of 04 second for each. Since the mechanism that the flux is constantly rotated and poured and applied to the wire reduces the evaporation of the flux to the extreme, the waste of the flux is cut and economic efficiency is great.

PERIPHERAL

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627

CPF-05

Perfeeder with self - learning function

Self-leaning function by means of integrated micro computer will feed a wire to the machine neatly. It controls the slack of wire and unique wire straightener improves the products quality. Furthermore, the great value of the processing and high work efficiency are realized by high speed wire feeding performance (Max. speed 3.3m/sec.)

CAS OP-7

Automatic wire feeder

Holding from inside the winded wire prevents it from breaking. Of course you can set the wire with its tray. With the rotation sensor, the wire is rotated as much as it is unwound (fed) from the winded wire.

CPD-06

Automatic wire supply unit

The unit supplies the wire while straightening the wire from the bobbin. The speed is controlled automatically, so that smooth supply is ensured.

CCP-02

Semi-auto Crimping Machine

Appearance from the head unit of “CASTUGNON C511”Crimp Force Monitor is installed, which can strictly monitor to the every crimping by the load cell on the ram of crimping machine. With “shot counter” and “rejected goods selector”.

SIS - 01

Automatic Seal Insertion Unit with Wire Stripper

This high technology machine can insert a seal and strip accurately the inner wire of multiple core cable, etc.. This machine installed “DF-01”, which is well-established disk feeder for CASTUGNON Series, and provides speedy and stable sealing. Using with semi-auto crimping machine “CCP-02”, the integrated processing from sealing to crimping can be arranged.

OR-01

One Push Oli Remover

This is originally developed for the proper oil removal for the seal. One touch oil removal, which used to be done manually. KODERA realized the user’s needs for the sealing. ( Patented product )

CRIMPING MACHINE

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627

Super Mute Terminal Crimping Machine

WL-1.5T/WL-2.0T/WL-3.0T/WL-4.0T/WL-8.0T

The semi-auto mute terminal crimping machine is suitable for crimping computer terminal, DC terminal, AC terminal, single grain terminal, and joint terminal. It is compatible with vertical and horizontal molds, and one machine is suitable for all terminal types by replacing the crimping molds.

CCP-02

Semi-auto Crimping Machine with Crimp Force Monitor

CPX

CPX Smart And Compact Ultralight, high-perfomance HX applicator, adoption, crimp foce monitor equipped

it is the birth of the high-quality semi-automatic pass "CPX" born form the khow-how of the HX Series, the highest grade of Castanon, and Kodera's original idea. Surprising dowsizing and weight reducation, and the adoption of the HX application with built-in IC tag with a reputation in the Castanon HX series work conditions and management information such as terminal-type wire size and crimp height are automatically loaded info the CPX body , so the setup replacement work is completed quickky. foresafe and operability, convention foot switches are used to push switches at fingertips. (LEFT of photo) Equipped with a crimp force monitor that always measures and display accurate. the 4.5-inch LCD color touch display is use to allow you to enter while looking at the screen display in the graphic.

CABLE AND WIRE STRIPPER

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627

Mira 32

CABLE-&-WIRE-STRIPPER

Strip standard wires quickly and electrically

MIRA230

MIRA230 Wire Stripper with Program

Compatible with 0.03 to 8sq. Various machining conditions are programmed.

Mira 340

Mira 340 and 340Q Premium quality with ACD for demanding wires

Broad range of applications The Mira 340 and 340 Q cover a large range of wire specifications up to 16 mm2 conductor cross section (AWG 5) and up to 72 mm strip length. They strip, cut and twist wires and cables with maximum precision. Even demanding insulating materials such as tough Teflon®, strong Kapton® and pliable silicon can be processed. Outstanding stripping quality Both models feature a rotary cutting head. This is combined with 4X blades to provide a strong and balanced grip when pulling off insulation and a high level of stripping quality. Both machines offer special functions such as offset pull-off with pre-pull-off to protect the conductor. Every wire and every sequence can be stored in the article library. Search and filter functions allow users to access the processing parameters and reproduce required articles error-free at any time.

Mira 440

Mira 440 AND 440 SF

Precise quality for coaxial, triaxial and hybrid cables

Cosmic 42R

Cosmic 42R – Coaxial Wire Stripper

The Cosmic 42R is the precision machine for multi-layered stripping of micro-coaxial cables

MKS100L

Cable Stripper for thick cable MKS100L

For thick cable, all function is set up by digital.Cable type setting helps you to set cutting depth.English and Japanese are available on display with Help mode. Cable Stripper for thick cable, all function is set up by digital MKS100L For thick cable, all function is set up by digital. Cable type setting helps you to set cutting depth. English and Japanese are available on display with Help mode.

MKS50X

Digital Cable Stripper MKS50X

MKS50XP( Power-up model ) THIN to THICK DIGITAL PROGRAMING & ROTARY Touch sensor model MKS50X-TS & MKS50XP-TS are also avalable.

MKS504

Digital cable stripper MKS504

Cable stripper by 4 blades rotary slide system and digital setting system. Power Up version is also available as MKS504P (Power of Rotary, Cramp and Slide are up)

MKS725S

Digital cable stripper MKS725S

MKS 504 class digital cable stripper High-end flagship model appears.

ROTARY ADAPTOR

This option is a compact table for very easy using the hand cable stripper.

MKHT630

Hand Cable Stripper MKHT630

SUITABLE FOR WIRING IN A SMALLELECTRIC BOX STRIPPER FOR SINGLE OR MULTIPLE CORE WIRES. IV, Eco-IV, Shielded wire STRIPPABlE.

MKS630V

ROTARY ENDLESS STRIPPER MKS630V

With Rotary & Spiral system, ensures sharp cut and endless strip.

CS60

AUTOMATIC STRIPPER CS60

Compact, High Speed, High-Accuracy

ST MAC Series

ST300V5 ,ST200V5 ,ST120V3 ,ST70V2

ZKS-12

Wire Stripper ZKS-12

SEMI CRIMPING MACHINE

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627

CAS-2T-C

Defects liability period:12 Months Degree of automation:Automatic Transport package:Wooden Case Specifications:700*500*430mm Certificate:CE/ISO:9001/ISO45001 Trademark:bozhiwang Country of origin:Changzhou, China

CAS-4T-C

CAS-6F

CAS-8T-C

CAS-16T

CAS-20TS

CAS-F108

CAS-6D

KM-802N

SEMI-CRIMPING-MACHINE

KM-802N Manual Crimping Press Crimping force : 2ton

KM-804N

KM-804N Manual Crimping Press

A new concept of noiseless crimping Press

KM-806N

KM-806N Manual Crimping Press

6ton Crimping Press A new concept of noiseless crimping Press

EC65

Desktop type electric crimping machine EC65

Flexible use thanks to a wide range of crimping dies

DH-1B

Electric tabletop crimping machine DH-1B

Crimping terminal for copper wire Electric terminal crimping machine dedicated for crimping terminal and crimping sleeve

MC40

Ferrule Strip Crimper MC40

Stripping and crimping in one work step

HPS-3S

MASTER ACE HPS-3S , 13S , 13S-TB

Attaching your manual crimping tools, soon it turns to be electric machine. Crimping work is eased and reduces operation. Foot switch drive system.

STC-220

Strip crimper STC-220

JAM applicator can be mounted as it is. It corresponds to a genuine applicator as an option. Perform strip length adjustment with servo control.

AC25T

Tabletop air ferrule crimping machine AC25T , AC100

Suitable ferrule AC25T:0.25～2.5sq / AC100T:4～10sq

DIN rail cutter

Manual cutting tool dedicated to aluminum DIN rails DIN rail cutter

DIGITAL CUTTING MACHINE

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627

KM-3100

KM-3100 Digital Cutting Machine

Applicable to the material which width is less than 100mm

KM-3200

KM-3200 Digital Cutting Machine

Applicable to the material which width is less than 200mm

KM-3300

KM-3300 Digital Cutting Machine

Applicable to the material which width is less than 300mm

KM-3400

KM-3400 Digital Cutting Machine

Applicable to the material which width is less than 400mm

KM-3600

KM-3600 Corrugated Hose Cutting Machine

Most appropriate for cutting an irregular surface such as corrugated hose. Two pairs of gear-type rollers for feeding.

KM-3900

KM-3900 Card Cable Cutting Machine

Card Cable Cutting Machine

CUT-P12

Air cable cutting machine CUT-P12

CUT-P12, CUT-P20, CUT-P20T, CUT-P30, CUT-P30T, CUT-P45

LC100

AUTOMATIC CABLE CUTTER with ENCODER-equipped LC100

High-Accuracy by ENCODER-equipped measurement roller and feeding roller

ZKC-16

DIGITAL CUTTER COMPACT TYPE ZKC-16

It is collected a function required for a compact body. Best machine for electric wire, heat contraction tube, vinyl tie, tape etc.

ZKC-25T-W1

DIGITAL CUTTER for VARNISHED TUBE ZKC-25T-W1

The special equipment machine for cutting varnished tube. Ideal machine for silicone tube or not slippery materials.

ZKC 200

DIGITAL CUTTER SHEET TYPE ZKC 200-200C

New shape of conveyor rollers Cutter supporting a wider width and suitable for thin wires.

ZKC-325

Digital cutter ZKC-325 Standard Series

ZKC-325 (Shear Blade) / ZKC-325T (Thin Blade) / ZKC-325C (Shear Blade PLC control) / ZKC-325CT (Thin Blade PLC control)

ZKF-25

FEEDER ZKF-25

Special new feed roller handles various work

PERIFERAL DEVICE OF CUTTING

SERVICE CALL : 084-1022297

HOT LINE : 089-7710627
